Phase Angle Controller Reovib Smart System Mini

IP 00, for DIN rail mounting

DESCRIPTION

REOVIB SMART SYSTEM MINI BASIC MODULE

In open design for DIN rail mounting with an output channel of max. 1A. The basic module has a supply for expansion modules, so further output modules can be connected in series up to a total current of 10A.

REOVIB SMART SYSTEM MINI EXPANSION MODULE

In open design for DIN rail mounting. An expansion module has one output channel max. 1A and can be set up together with the basic module and several expansion modules.

ADVANTAGES

  • Cost-effective phase-angle control systems with vital functionality
  • Can be used as a standalone device or in a modular design for control of a complete feed system
  • Output current up to 6A
  • DIN rail mounting
  • Versions available with fill level/overflow control

TYPICAL APPLICATIONS

Weighing systems, multiple-head weighing wagon, conveyor & assembly automation, sorting systems

TECHNICAL SPECIFICATION
