Resistor Reohm Bw 155 – Combination

Max continuous power: 30,000 W

DESCRIPTION

Braking resistor for drives with frequency converters of high power. Mounting close to the frequency inverter.

ADVANTAGES

• Fast connection
• Good heat dissipation
• Adaptation to every frequency converter
• Compact, modular structure
• High degree of protection up to IP66
• Easy to assemble thanks to 4-hole fastening
• Optionally with cover
• Optionally also for aggressive environments (e.g. salt spray)

TYPICAL APPLICATIONS

Braking resistor for drives with frequency converters of medium to high power. Mounting inside and outside the control cabinet is possible.

SERVICES

• degree of protection: IP 20 / IP 65 / IP 66
• test voltage: 2.5 kV AC
• ambient temperature: 10+40ºC

other services on request
other mounting dimensions on customer request

* With small resistance values, the conductor cross-section is adapted to the current.
