Sinusoidal Filter Cnw 932
Two-phase Sinusoidal filter
ADVANTAGES
- low thermal heating
- low noise
- Production according to UL insulation system E 251513 is possible
- easy connection
- Adaptation to motor cables up to 1000 meters possible
- The shielded cable can be saved
TYPICAL APPLICATIONS
Drive technology for motor drives, e.g. B. Mechanical engineering, elevators/escalators, pumps, conveyor technology, ventilation and air conditioning technology, robotics, automation technology, power supplies, wind turbines
TECHNICAL SPECIFICATIONS
- Ambient temperature: 50 ° C
- Protection class: IP 00
- Insulation class: F
- Linearity: LN at 1.2 x IN u. ≥ 0.8 x LN at 1.5 x IN
- Test voltage: 3 kV
- Nominal voltage: 230 V.
- UK: 6.15%
- Overvoltage category: 2
- Degree of pollution: 2
- Cooling: ON
- Switching frequency: ≥ 4 kHz
- Current ripple: ≤ 20% at 4 kHz
