Active Current Transformer Series Wko-2c-b

Double core technology closed-loop current transformers for railway engineering

DESCRIPTION

The current transducer WKO-2C-B with hall effect elements and double-core technology has an extended frequency response of up to 150 kHz and an accurate phase response. The WKO-2C-B guarantees an increased current measurement accuracy of better than 0.3% in the whole frequency range: DC to 150 kHz.

A completely redesigned electronics ensure that the new C/L current transducer has better drift compensation and an extended temperature range from -40°C to 85°C.

Modular design

The current transformer has a modular design which allows a variety of mounting options. The cost-effective basic model consists of a housing with screw terminals, bushing for cable and holes for fixing. Optionally, the transducers are available with a mounting kit for busbars, Molex connectors and feet for horizontal or vertical mounting.

According to

  • EN 50178:1997
  • UL 94-V0
  • EN 50178
  • EN 50155:2007
  • IEC 61373:2010

ADVANTAGES

  • Fulfils the required railway engineering safety standards: EN 50178, EN 50155:2007 and IEC 61373:2010
  • Shock- and vibration tested according to IEC 61373:2010
  • High current measurement accuracy of 0.3%
  • Modular mounting plates providing universal mounting options
  • Lower sensitivity to external magnetic fields
  • Bidirectional and isolated current measurement up to ±750A current output
  • Modular mounting plates
  • REO double core technology
  • All materials manufactured using UL-listed materials

TECHNICAL DATA

  • Accuracy: better than 0.3%
  • Ambient temperature: -40 ° C… + 85 ° C
  • Storage temperature: -40 ° C… + 90 ° C
  • Primary nominal current: 300 – 2000 A
  • Measuring range: 0… 4000 A
  • Frequency range: DC – 150 kHz

MECHANICAL DATA

ELECTRICAL DATA

ACCURACY AND DYNAMIC DATA

ISOLATION DATA
