Emc Filter Cnw 107.3/690

High-current mains filters (3 lines)

DESCRIPTION

The EMC filter is specifically for the suppression of high-current applications in wind energy and industrial applications designed. This filter series is for the voltage levels of 480V and 690V constructed.

The filter can be delivered in various casing versions. So it can be adapted to different environmental conditions.

There are also versions for offshore applications possible.

ADVANTAGES

  • specifically designed for high performances
  • suitable for offshore applications
  • compact design
  • good heat dissipation
  • rail connector
  • fast installation

TYPICAL APPLICATIONS

The EMC filter is specifically for the suppression of high-current applications in wind energy and industrial applications designed.

TECHNICAL SPECIFICATIONS

  • Conforming to: VDE 0565-3 / IEC 950 / UL 1283
  • Test voltage: L-N 2100 V, DC 1s, L/N-PE 2700 V, DC 1s
  • Overload: 1,5 x I 1 min/h
  • Climatic category: DIN IEC 68 Teil 1 25/085/21

TECHNICAL SPECIFICATION

DIMENSIONS IN MM
