Emc Filter Cnw 304

By using a mains choke the upper harmonics are reduced and the starting current is limited. This increases the efficiency and discharges the leads.

ADVANTAGES

• Easy installation
• Small footprint
• Reduction of cable looms in control panels
• Attenuation of higher harmonics
• Low hum vacuum impregnated choke
• Reduced start-up current
• The choke is rated for a short-circuit voltage of 4%, at rated current, as standard

TYPICAL APPLICATIONS

Interference suppression of frequency converters with IGBTs and reduction of harmonics (conforming to VDE 0160/EN 61800-3 class B)

TECHNICAL SPECIFICATIONS

• Conforming to: VDE 0565-3 / IEC 950 / UL 1283
• Test voltage: L-L 2100 V, DC 1s, L-PE 2700 V, DC 1s
• Overload: 1,5 x I 1 min/h
• Climatic category: DIN IEC 68 Teil 1 25/085/21
