Emc Filter N Cnw 114

Three-phase mains filters with increased attenuation, 3 lines

DESCRIPTION

When electronic components are panel-mounted in a cabinet, in most of the cases the same circuits with different power are required. To avoid permanent modifications of the apertures, several power ranges should ideally be combined. The filters of this series, within the most important power range, have equal fixing dimensions, so the filters can be replaced.

ADVANTAGES

• compact construction
• easy installation
• low-temperature rise
• touch-proof terminals
• IT-versions possible

TYPICAL APPLICATIONS

Frequency converters for motor drives, wind power installations and power supply units

TECHNICAL SPECIFICATIONS

• Conforming to: VDE 0565-3 / IEC 950
• Test voltage: L-L 2100 V, DC 1s, L-PE 2700 V, DC 1s
• Overload: 1,5 x I 1 min/h
• Climatic category: DIN IEC 68 Teil 1 25/085/21

* On request also available with 690V.
Also available as a variant with cULus certification. After request, we will send you the corresponding data sheet.
