Harmonic Filter Cnw 999
Compensating choke (7 or 14% detuning factor)
DESCRIPTION
Reactive Power and harmonics compensation equipment; Protection of capacitors
ADVANTAGES
- Low inductance tolerance
- Linear behaviour even with current higher than rated current
- Connection on terminals or wire at the option
- Low noise
TECHNICAL SPECIFICATIONS
- Conforming to: DIN EN 61558-2-20
- Test voltage: L-L 2100 V, DC 1 min L-PE 2700 V, DC 1 min
- Overload: 1,5 x INenn 1 min / h
- Climatic category: DIN IEC 60068-1
- Thermal class: H
- Protection degree: IP 00
- Nominal Voltage: 400 V
- Rated current: 9,1 – 80 A
- Inductance: 0,78 – 14,5 mH
DIMENSIONS IN MM
