Mains Choke N Cnw 905

Three-phase mains choke 2% Uk

DESCRIPTION

Power Noise Reduction – save up to 15% on energy costs. A mains choker relieved the supply network by compensating the harmonics reactive power. The harmonics and commutation notches are reduced strongly. By using a mains choke the inverter electronics and DC capacitors will be protected.
Starting currents and current peaks are reduced by up to 30%. Mains chokes help to comply with international power quality standards IEEE 519 or EN 61000-3-2.

ADVANTAGES

  • Compact design
  • Extended lifetime of electrical consumers
  • Low-temperature rise
  • Attenuation of current spikes up to 30%
  • Reduction of input current up to 15%
  • Low noise
  • Production according to UL insulation system E251513 is possible

TYPICAL APPLICATIONS

Drive systems for motor drives:
Mechanical engineering, Elevators/escalators, Pipes, Conveyor technology, Ventilation and air conditioning, Robotics, Automation technology, Power supplies, Wind turbines

TECHNICAL SPECIFICATIONS

  • Rated voltage: U ≤ 3 x 500 V
  • Short circuit: Uk 2% (400VAC/50Hz, INenn)
  • Frequency: 50/60 Hz
  • According to: EN 60289 / EN 61558
  • Test voltage: L-L 2500 V, DC 1min; L-PE 2500 V, DC 1min
  • Insulation class: T40/F
  • Protection rating: IP00
  • Climatic categorie: DIN IEC 60068-1
  • Overload: 1,5 x INenn 1 min / h
  • Design: mounted on the footprint

TECHNICAL SPECIFICATION

DIMENSIONS IN MM
