Mains Choke N Cnw 901

Single-phase mains choke 4%

DESCRIPTION

Power Noise Reduction – save up to 20% on energy costs. A mains choker relieved the supply network by compensating the harmonics reactive power. The harmonics and commutation notches are reduced much. By using a mains choke the inverter electronics and DC capacitors will be protected.

Starting currents and current peaks are reduced up to 60%. Mains chokes help to comply with international power quality standards IEEE 519 or EN 61000-3-2.

ADVANTAGES

  • Compact design
  • Extended lifetime of electrical consumers
  • Low-temperature rise
  • Attenuation of current spikes of up to 60%
  • Reduction of the input current up to 20%
  • Low noise
  • Production according to UL insulation system E251513 is possible

TYPICAL APPLICATIONS

Drive systems for motor drives: Mechanical engineering Pumping, Conveyor technology, Ventilation and air conditioning, Robotics, Automation technology, Power supplies

TECHNICAL DATA

  • Rated voltage: U ≤ 250 V
  • Short circuit: Uk 4% (230VAC/50Hz, INenn)
  • Frequency: 50/60 Hz
  • According to: EN 60289 / EN 61558
  • Test voltage: L-PE 2500 V, DC 1min
  • Insulation class: T40/F
  • Protection rating: IP00
  • Climatic categorie: DIN IEC 60068-1
  • Overload: 1,5 x INenn 1 min / h

Design: mounted on footprint

TECHNICAL SPECIFICATION

DIMENSIONS IN MM
