Phase Angle Controller Reovib RTS System

DESCRIPTION

RTS SYSTEM BASIC MODULE

In open type of construction for assembly on a DIN rail with an output channel of max. 6A with fill level/overflow control and mains voltage compensation. The basic module has a supply for the expansion modules, so further output modules up to a total current of 10A can be connected.

RTS SYSTEM EXPANSION MODULE

In open design for assembly on a DIN rail. The expansion module has an output channel max. 6A with fill level/overflow control and mains voltage compensation and can be set up together with the basic module and several expansion modules.

REOVIB RTS SINGLE

In open design for assembly on a DIN rail with an output channel of max. 6A, fill level/overflow control and mains voltage compensation.

ADVANTAGES

• Cost-effective phase-angle control systems with protection class IP00 for installation in a control cabinet
• Can be used as a standalone device or in a modular design for several outputs
• Output current up to 6A
• Fill level/overflow control
• Mains voltage compensation with constant vibration amplitude
• Adjustable soft start ramp time

TYPICAL APPLICATIONS

Conveyor & assembly automation, conveyor technology, sieving technology
