Programmable Phase Angle Controller Reovib MTS 620

IP 54, two-channel control


The control unit REOVIB MTS 620 is a phase-angle controller for regulating of the conveying speed of vibratory feeders. All parameters can be entered via an LED display integrated in the front panel. User-specific settings can be stored and recalled. The device is available in IP20.

The REOVIB MTS series includes single-channel, two-channel and three-channel control units for vibratory conveyor drives. These are phase-angle control systems. The vibration frequency of the conveyor can be the same as or twice the frequency of the input voltage. (Other frequencies are possible depending on the type). Plug and socket connections for all inputs and outputs make rapid installation possible and facilitate the combination of several devices with each other or with external control systems. The devices use digital technology and are operated via a LED or LCD display and buttons. All settings can be made without the housing having to be opened.


  • Phase-angle control with programmable functions
  • Single-channel, two-channel or three-channel control for the optimal control of the complete conveyor system
  • Digital setting of all parameters via LED display or multiline LCD display (MTS 443 LCD)
  • In IP54 or IP20 design (MTS 441)
  • Automatic mains voltage adjustment
  • Material flow control
  • Various sensor logic functions can be set
  • Adjustable soft start
  • With fill level/overflow control
  • Integrated mains voltage compensation with constant vibration amplitude
