Test Choke Rpd 9039

Three-phase load choke

DESCRIPTION

Drive inverters or output filters must be tested at rated current by using typical motor generators. Due to the high costs, the specimens can be loaded alternatively with chokes which have sufficient linearity and do not exceed the temperature limit at higher frequencies.

ADVANTAGES

• Small dimensions
• Cost-effective solution

TECHNICAL DATA

Cooling: AN

Isolierstoffklasse: F

Climatic category: 25/085/21 DIN IEC 68 Teil 1

Max. winding temperature: 140 °C

Protection rating: IP 00
