Sinusoidal Filter Cnw 931

Single-phase sinusoidal filter 6,15% Uk

DESCRIPTION

Smoothing of the current and voltage in order to realize long connecting paths.

ADVANTAGES

  • Low temperature rise
  • Low noise
  • Manufacturing according to UL Insulation System
  • E 251513 possible
  • Easy installation
  • Adaptation to motor cables up to 1000 meters possible
  • Saving of the shielded cable possible

TYPICAL APPLICATIONS

Drive technology for motor drives, e.g. mechanical engineering elevators / escalators pumping materials, handling, ventilation and climate technology, robot technology automation technology, Power supply and wind turbines

TECHNICAL SPECIFICATIONS

  • Ambient temperature: 50 °C
  • Protection rating: IP 00
  • Insulation class: F
  • Linearity: LN bei 1,2 x IN u. ≥ 0,8 x LN bei 1,5 x IN
  • Test voltage: 3 kV
  • Rated voltage: 230 V
  • Uk: 6.15 %
  • Overload category: 2
  • Pollution degree: 2
  • Cooling: AN
  • Switching frequency: ≥ 4 kHz
  • Current ripple: ≤ 20 % bei 4 kHz

TECHNICAL SPECIFICATION
