Toroidal Core Transformer Rft-mv
Toroidal fixed transformer with a sealed centre hole as a mains, auto, safety or isolation transformer
DESCRIPTION
The toroidal fixed transformers with sealed centre holes or sealed sockets have the same advantages as the open transformers, however, offer a good mounting solution for the transformers. The costs for an additional mounting option are cut in this series of transformers and replaced by a central screw, which only requires a short set-up time. A safe distance to the mounting surface is ensured.
ADVANTAGES
- Integrated mounting plate with partial sealing
- No humming
- Low magnetic stray field
- Low voltage drop
- A high degree of efficiency
- Direct mounting option with just one screw
- Safe distance to the mounting surface
- Connection with wires or stranded wires
- Standards: EN 61558; EN 60601
- The costs for an additional mounting option are cut in this series of transformers and replaced by a central screw, which only requires a short set-up time. A safe distance to the mounting surface is ensured.
TECHNICAL SPECIFICATION
