Variable Transformer Drte

Three-phase variable column-type transformers (auto windings, IP 00)

DESCRIPTION

The REO column-type variable transformers complement the REOVAR series for currents up to 1000A with a fine-step adjustment of the output voltage at a constant current at the output.

The waveform of the sine wave is preserved – like that,  EMC problems cannot occur over the entire operating range of 0 – 1000A. All products in the series come with UL–listed materials.

The REO construction enables easy handling of the carbon rolls and the spindle – the copper-bevel gear allows a hysteresis-free adjustment of the output voltage even at high adjustment speed of the drive motor. Thus REO variable column transformers are perfect for high-performance adjustment.

REO-column type variable transformers conform to EN 61558-2-14

ADVANTAGES

• Closely stepped adjusting of output voltages
• Low-loss cores
• Vacuum impregnated windings
• Windings virtually maintenance free
• UL-listed materials
• Available in IP 00 and IP 20
• Wide range of accessories
