Single-phase Thyristor Controller Reotron Ew 509

Thyristor power regulator

DESCRIPTION

The range of REOVIB System 500 modules comprises phase-angle controllers for vibratory feeders and a timer module used with systems that have track control.

The REOVIB 509 is designed for controlling bowl or linear feeders up to 15 A current rating. The output frequency 50Hz/100Hz (60Hz/120Hz) is selected to suit the feeder. In the regulation circuit, there is built-in compensation for mains variations. The feed rate setpoint can be derived from a potentiometer, a voltage signal 0…+10 VDC or a current signal 0…20 mA. The setpoint range can be linearised by means of two trimmers Umin/Umax.

Furthermore, an enable input is provided for start/stop operation and there is a control input for use with a track control module (REOVIB 513).

Fixings are provided for DIN rail mounting according to EN 50022-35.

ADVANTAGES

• Mains voltage compensation
• Selectable vibrating frequency 50/100 Hz or 60/120 Hz
• Enable input 24 VDC or contact
• Snap-on mounting for 35 mm DIN rail
• Control input for track control using the REOVIB 513

TECHNICAL SPECIFICATIONS

Input voltage : 230 / 400 V + 6% / – 10%

Output voltage : 0…Ue V

Output Current: 15 A
